LKAD026D 29W 25-42V 700mA Dimmable LED drivers
  • LKAD026D 29W 25-42V 700mA Dimmable LED drivers

LKAD026D 29W 25-42V 700mA Dimmable LED drivers

  • Product model : LKAD026D
  • Input voltage : 200-240Vac
  • Output power(W) : 29W
  • Output voltage : 45-80Vdc/25-42Vdc
  • Output current(A) : 170-320mA/330-700mA
  • Light adjustment : Triac Dimming
  • Size(MM) : 135 x 45 x 28mm
Authentication:
Skype
  • Product Detail
  • Send Inquiry
  • Download

LKAD026D SAA CE approved 29W 25-42V 700mA Dimmable LED drivers

Features

  • 200-240VAC(50/60Hz) Input
  • Isolated, leading (or trailing) triac dimming,dimming much smoothly;
  • Flicker free
  • Hight efficiency,hight PF,good steady;
  • Short circuit,over voltage,over current and over temperature protection;
  • 100% full load burn-in test;
  • CE approved;
  • ndependent, ClassⅡ constant current type;
  • degree of protection IP20;
  • suitable for LED lighting,ceiling light,down light and panel light;
  • 3 years warranty.



More Details

Model LKAD026D
輸入             Input AC電壓范圍/AC Voltage range 200-265V
頻率/Frequency 50/60hz
諧波/THD
功率因數/Power factor 0.97/200VAC
輸出      Output 額定電壓/Rated voltage 42V
空載電壓/No-load Voltage 46V
DC電壓范圍/DC voltage range 20-42
DC電流范圍/DC current range 690-710mA
電流精度/Current precision (+/-)3%
額定功率/Rated power 29W
開機延時/Setup Time ≤0.5s/230VAC
使用環境    Environment Requirements 工作溫度/濕度要求                    Operating Temp./RH -30～+45℃/20～95%
儲存溫度,濕度要求                   Storage Temp./RH -40～+80℃/10～95%
安全和電磁兼容 認證編號/Certificate LVD
EMC
其他 尺寸/Size L135mmxW45mmxH28mm
重量/Net weight 116g
